TECHNICAL SPECIFICATION

✓  BODY Aluminum die cast parts with all critical movements, based on ball-bearing guides.

✓  OBSERVATION HEAD  Trinocular head 45⁰ inclined 360⁰ rotatable.

✓  STAGE  Co-axial mechanical stage slides for frictionless and jerk free movement.

✓  CONDENSER  Moveable condenser (NA 1.2) with IRIS diaphragm and filter holder on rack and pinion.

✓  FOCUSING  Coaxial coarse and fine focusing mechanism.

✓  OBJECTIVES  Semi plan objectives 5X, 10X, 45X(SL), and 100X (SL) oil (anti fungus).

✓  EYEPIECE  WF 10x pair.

✓  NOSEPIECE  Quadruple Nosepiece.

✓  SAFETY DEVICE  Adjustable down stopper  for preventing accidental damage to slides.

✓  ILLUMINATION  Variable illumination control.

✓  PACKAGING  Full moulded thermocol container.

OPTIONAL ACCESSORIES

•      LED illumination with battery backup for uninterrupted research and learning.

•      Wooden box with lock and key.

•      Binocular head/slide roof trinocular head.

•      Din plan achromatic objectives 5X, 10X, 45X (SL) and 100X (SL) OIL.

•      LED illumination system.
