The Weld Penetration Analysis System is a specialized digital imaging and analysis solution designed to measure and evaluate weld quality, penetration depth, and structural integrity with high precision. By combining advanced metallurgical microscopy, image analysis software, and digital cameras, this system provides quantitative and qualitative evaluation of weld sections for R&D, production, and quality control.

It enables engineers and metallurgists to analyze weld bead geometry, penetration profiles, porosity, cracks, and heat-affected zones (HAZ) with reliable accuracy. The system is widely used in aerospace, automotive, shipbuilding, pipeline, heavy engineering, and welding research institutions to ensure compliance with international welding standards.

🔑 Key Features

• System Type: Weld Penetration Analysis System with imaging & analysis software

• Optical Integration: Works with metallurgical microscopes (upright or inverted)

• Camera: High-resolution digital imaging for accurate documentation

• Software Functions:

  • Weld bead & penetration depth measurement

  • Weld geometry analysis (throat thickness, reinforcement, width, area)

  • Heat-affected zone (HAZ) characterization

  • Porosity and crack detection

  • Statistical analysis & report generation

• Accuracy: Micron-level measurement precision

• Reports: Automated data reporting with images & graphs for QC documentation

• Applications: Aerospace, automotive, pipelines, heavy engineering, structural welding, R&D, and metallurgical quality control
