The Advanced Binocular Research Microscope ABTZ – 6000 TTCM is a cutting-edge research-grade microscope designed for professional laboratories, medical research, and advanced academic studies. It incorporates infinity-corrected plan achromatic optics, providing exceptional clarity, high resolution, and superior contrast for demanding research applications.

This model features a Seidentopf binocular head, precision double-layer mechanical stage, and ergonomic co-axial focusing system, ensuring both ease of use and accuracy. Its Köhler LED illumination system delivers bright, uniform, and flicker-free lighting, ideal for extended observation of biological, pathological, and clinical specimens.

🔑 Key Features

• Magnification Range: 40x – 1000x

• Observation Head: Seidentopf binocular head, inclined 30°, 360° rotatable, interpupillary distance 48–75 mm, diopter adjustment (±5)

• Eyepieces: Extra wide-field 10x (paired), anti-fungal coated, high eye-point design

• Objectives: Infinity-corrected Plan Achromatic objectives – 4x, 10x, 40x (spring-loaded), 100x oil immersion (SL), anti-fungal treated

• Stage: Double-layer mechanical stage with 2-plate design (approx. 180×160 mm), co-axial controls on ball-bearing guideways, X-Y travel ~ 76×50 mm

• Focusing System: Co-axial coarse and fine focusing, tension adjustment, pre-focusing lever, fine division 0.002 mm

• Nosepiece: Reverse angle sextuple nosepiece mounted on ball bearings for smooth objective changes

• Condenser: Swing-out Abbe condenser N.A. 1.25 with adjustable iris diaphragm and filter holder

• Illumination: High-efficiency Köhler LED illumination with brightness control (3W/5W LED lamp)

• Mechanical Build: Heavy-duty, ergonomic body design for long-duration use in professional labs
