The Fluorescence Upright Research Microscope ABTZ – 888 PRO is a professional-grade fluorescence research microscope designed for advanced biomedical, molecular biology, microbiology, and clinical applications. With its infinity-corrected Plan Achromatic optics and a dedicated PRO fluorescence system, it ensures sharp, high-contrast imaging in both brightfield and fluorescence modes.

This model is equipped with a trinocular head, enabling simultaneous visual observation and digital imaging, making it ideal for documentation, teaching, and advanced research. The PRO edition is optimized for long working sessions, featuring ergonomic controls, high-efficiency fluorescence illumination, and multiple filter cubes for multi-channel fluorescence imaging.

🔑 Key Features

• Microscope Type: Upright fluorescence research microscope (PRO edition)

• Observation Head: Trinocular Seidentopf head, 30° inclined, 360° rotatable, with trinocular port for camera integration

• Eyepieces: Extra wide-field 10x (paired), F.O.V. 22 mm, anti-fungal coated, high eye-point design

• Objectives: Infinity-corrected Plan Achromatic objectives – 4x, 10x, 40x (spring-loaded), 100x oil immersion

• Stage: Double-layer mechanical stage with low-drive co-axial controls, X–Y travel ~76 × 50 mm

• Focusing: Co-axial coarse & fine focusing with tension adjustment & pre-focusing lever, fine division ~0.002 mm

• Condenser: Abbe condenser N.A. 1.25 with iris diaphragm, phase contrast compatible

• Illumination:

  • Brightfield: Köhler LED illumination with adjustable brightness

  • Fluorescence: PRO fluorescence attachment with high-intensity LED/Hg lamp and multi-filter cubes (Blue, Green, UV; optional Red)

• Special Features (PRO Edition):

  • Optimized fluorescence system for high-sensitivity imaging

  • Supports multi-channel fluorescence imaging

  • Ergonomic, stable design for long-duration lab use

• Applications: Immunofluorescence, microbiology, molecular biology, cytogenetics, oncology, pathology, and clinical diagnostics
