The Trinocular Research Microscope ABTZ-779 is a high-performance optical instrument designed for advanced research, clinical applications, and professional laboratory work. Featuring a trinocular observation head, it allows both visual study and micro-photography simultaneously, making it ideal for documentation and analysis. With a magnification range of 50x – 1000x, smooth focusing, and precision optics, this microscope delivers sharp, clear, and high-contrast images for reliable results.

Key Features:

• Magnification: 50x – 1000x

• Observation: Trinocular head, inclined 45°, 360° rotatable with interpupillary & diopter adjustment

• Stand: Rigid, heavy, and stable for professional use

• Focusing: Coarse & fine focusing knobs with precision (1 div. = 0.002 mm)

• Stage: Horizontal mechanical stage 120×140 mm with fine vernier graduations, co-axial X–Y movement (50×70 mm)

• Illumination: Built-in 3W LED lamp with adjustable brightness

• Condenser: Abbe condenser N.A. 1.25 with iris diaphragm, swing-out filter holder, rack & pinion focusable

• Nosepiece: Quadruple revolving nosepiece with positive click stops

• Objectives: Achromatic 5x, 10x, 45x & 100x oil immersion (SL)

• Eyepieces: Wide-field 10x (paired), anti-fungus coated, F.O.V. 18 mm

• Additional Feature: Trinocular port for digital imaging / photography

Applications:

• Advanced biological and medical research

• Clinical diagnostics & pathology labs

• University-level teaching & training

• Microbiology, cytology, and histology studies

• Photomicrography & digital imaging in research
