Infant Radiant Warmer with Detachable Baby Cradle

The Infant Radiant Warmer is designed to provide controlled thermal support for newborn care. Equipped with a microprocessor-based temperature controller, multiple operating modes, comprehensive safety alarms, and a detachable baby cradle, the system facilitates effective temperature management and patient monitoring.

Key Features

1. Fixed-height warmer with detachable baby cradle mounted on four 100 mm wheels, including two wheels with brakes.
2. Stainless steel baby tray with waterproof zipped-cover mattress (density approx. 21–25 kg/m³).
3. Continuous head-up and head-down positioning facility.
4. Integrated X-ray cassette holder.
5. Collapsible and lockable side supports made of unbreakable polycarbonate material.
6. Slots provided for sensor and ventilator tubing.
7. Side tray for monitor placement.
8. Stainless steel infusion rod with facility to mount syringe/infusion pumps.
9. Lower shelf below the baby tray to facilitate under-surface phototherapy.
10. Three storage drawers for accessories and consumables.
11. Swiveling overhead heater assembly with ceramic heater and halogen observation light.
12. Keypad lock facility for secure operation.

Dimensions

Display System

1. LED display for Skin Temperature, Air Temperature, Set Temperature, and Heater Power Percentage.
2. Display resolution of 0.1°C.
3. LCD display for operating modes, alarm messages, timer, and skin temperature in °F.

Temperature Accuracy

1. Thermistor-based temperature sensor.
2. Accuracy of ±0.2°C.
3. Temperature calibration not required.

Operating Modes

Skin Servo Mode

1. Temperature Range: 34°C to 38°C
2. Resolution: 0.1°C

Air Mode

1. Temperature Range: Room Temperature to 39°C
2. Resolution: 0.1°C

Manual Mode

1. Adjustable Heater Power: 0–100%
2. Increment: 5%
3. Time Duration: 15 Minutes

Pre-Warm Mode

1. Adjustable Heater Power: 0–25%
2. Increment: 5%
3. Time Duration: 30 Minutes
4. No alarm activation during pre-warm mode.

Electrical Specifications

1. Microprocessor-based temperature controller.
2. Operating Voltage: 220–240 VAC.
3. Frequency: 50 Hz.
4. Maximum Power Consumption: 800 W.
5. Overhead swiveling heater box.
6. Ceramic Heater: 650 W.
7. Parabolic reflector with safety grill.
8. Halogen observation light: 12V / 50W.

Comprehensive Safety Alarm System

The unit features audio alarms with a 10-minute mute facility and visual alarm indications on the LCD display.

Applications

1. Neonatal Care Units
2. Infant Thermal Management
3. Patient Observation and Monitoring
4. Under-Surface Phototherapy Support
5. Healthcare Facilities Requiring Controlled Neonatal Warming Systems
